This modern spark-ignition 16V engine is equipped with BOSCH fuel injection. It provides maximal output and torque in low revs, which implies its fundamental advantage in harsh off-road operation. During the on-road operation it offers swift moving offs and cultivated running. Its sufficient output and gear ratios enable problem-free motorway operation. This engine type is suitable for a modification to LPG fuel and can be diagnosed via OBD connector.
Description
Vehicle category
N1G
Drivetrain
4x4
Operating weight
1740 kg
GVWR
1330 kg
Number of seats / doors
2
/
2
Clearance
210 mm
Wheelbase
2 550 mm
Front gauge
1 475 mm
Rear gauge
1 468 mm
Fuel tank capacity
50 L
The UAZ 3303 AMC Singlecab NVN features its classic and simple chassis devised from the iconic Bukhanka. Behind it is plenty of room for superstructures. It can be used in all seasons for all purposes, while keeping its UAZ legacy, which is: durability, robustness, reliability and off-road capabilities.
Price on request
Prices are without VAT and include specifications for the Czech and Slovak markets.
Engines
Fuel
Petrol
Engine capacity
2 693 cm3
Output
83 kW
/
4 250 rpm
Torque
198 Nm
/
2 500 rpm
Fuel consumption
Benzín: 13,1-13,9, LPG 13,7-16,5 l/100km
CO2
Benzín 303-322, LPG 222-266 g/km
ZMZ 40911
"If it ain't broke, don't fix it." UAZ has been following this motto for the ''Bukhanka'' models for several decades. This vehicle offers features which are more than desirable for working off-road. There is not one useless electronic- there is only pure mechanics with military heritage.
Equipment
Colours
Light grey
Khaki green
General
Petrol engine ZMZ 40905 MPI AMCE6
5-speed manual transmission
UAZ additional gearbox
Mechanically operated additional gearbox
Parking brake with effect on cardan shaft
Front and rear Spicer axle
Power steering
Safety
Front safety belts
Ignition with anti-theft system
Front disc brakes
Rear drum brakes
ABS
Interior
All-metal dashboard in colour of the body
Onboard computer
Socket 12V in front panel
Storage space
Lockable storage box
Inside rear view mirror mounted on windshield with modes day/night
Adjustable beckrest part of the driver's seat
Sliding driver's seat
Lighting in front part of the interior
Washable interior
Exterior
Non-metallic colours
Metal front bumper
Metal rear bumper
Front plastic wheel arches
Rear axle with semi-elliptic springs
Steel rims with tyres 225/75 R16
Full-fledged steel spare wheel
Rear view mirrors in black colour
Optional accessories
Electronically operated rear differential lock
- included
- not available
- for surcharge
- additional info
Because it's built for offroad driving, the Bukhanka offers equipment elements which manage to conquer even the most demanding terrain. At the same time it retains reliability which is provided by using mechanics instead of electronics.
Technical Description
Vehicle
Make
UAZ
Type
330365
Vehicle category
N1G
General construction characteristics
Number of axles
2
Number of wheels
4
Driving axles (number / position / connection)
2
Main dimensions
Wheelbase
2 550
mm
Length
4538-4748
mm
Width
1996
mm
Height
2066-2555
mm
Weights
Mass of the vehicle in running order
1740 kg
Technically permissible maximum masses
echnically permissible maximum laden mass
3070
kg
Technically permissible mass on axle 1
1 435
kg
Technically permissible mass on axle 2
1 635
kg
Technically permissible maximum mass of the combination
5 570
kg
Technically permissible maximum towable mass in case of
Centre-axle trailer
2500
kg
Unbraked trailer
750
kg
Technically permissible maximum static vertical mass at the coupling point
100
kg
Power plant
Manufacturer of the engine
Zavolzskyj motornyj zavod, Russia
Engine code as marked on the engine
40911
Number and arrangment of cylinders
4
Engine capacity
2693
cm3
Fuel
Petrol
Max. net power [kW] at [rpm]
83 / 4250
Maximum speed
Maximum speed
120
kph
Axles and suspension
Axle track 1
1 475
mm
Axle track 2
1 468
mm
Tyre/wheel combination (original design)
6,5J x 16, 225/75 R16 108H
Body
Number and configuration of doors
2
Number of seating positions (including driver)
2
Enviromental performances
Sound level
Exhaust Emission level
EURO 6
Information
Payment terms and conditions
An advance payment of at least 80% is required when ordering a new vehicle from Russia. It can be agreed individually.
Vehicle delivery period
When ordering a new vehicle from Russia the delivery time is 6-9 months if the vehicle is not in stock at the manufacturer.
UAZ AMC vehicle warranty conditions
The standard warranty period provided by the importer according to the vehicle price offer is 24 months or up to 100 000 km driven, whichever occurs first. Warranty conditions can be agreed individually with the business entities: the vehicle warranty period can be reduced upon agreement with the customer in the form of a discount, or extended upon a surcharge. The warranty period cannot be reduced in case the customer is a natural person. Terms and conditions are governed by bilaterally signed vehicle warranty conditions which constitute an integral part of the purchase agreement and handed over documentation.
UAZ AMC vehicle warranty repairs
In case a failure occurs within the warranty period, it can be claimed:
1. at warranty service of AMC spare parts s.r.o., business address: Radíkovice 19, Hradec Králové 503 27, Czech Republic or at another chosen warranty service centre within the AMC service network (Warranty service centre is authorized to perform warranty repairs without a consent of the seller)
2. at the seller, who, if necessary, issues a single license - written agreement with the specific defect repair at the selected service centre within the AMC network (Authorized Service is not authorized to perform warranty repairs without the consent of the seller)
Regular service of UAZ AMC vehicles
1. AMC Full-Service:
Regular vehicle service (as prescribed by the periodic maintenance in the service booklet) is provided by a service centre of the importer, authorized by AMC spare parts s.r.o., business address: Radíkovice 19, Hradec Králové 503 27, Czech Republic and through AMC full-service. The vehicle can be for a pre-agreed fixed fee regularly taken to be serviced by the importer and after performing the service it is immediately returned to the customer. There is full liability insurance for the vehicle taken. We recommend it for vehicles used in the Czech Republic and neighbouring countries.
2. Service through the network of authorized AMC service centres:
Regular vehicle service (as prescribed by the periodic maintenance in the service booklet) is provided by a contractual authorized service centre of the importer. It is guaranteed that the service centre is located within 40 km from a place of the vehicle operation. The authorized service centre is obliged and entitled to carry out the vehicle full service and repair works paid by the customer. The authorized service centre is not automatically entitled to exercise the rights of the buyer resulting from the warranty, but after a specific written consent of the seller it can be entitled to settle them.
3. Find your service
Do you know a service centre in your neighbourhood that you would like to use for the maintenance of your new UAZ vehicle? Do you know that they charge reasonable prices, have an experienced staff, good references and satisfied customers? Just ask. In case of interest, we are ready to sign a vehicle service authorization contract with your chosen service centre and to include it into the AMC authorized service network.
Separate supplies of spare parts
Spare parts and additional equipment for UAZ AMC vehicles are anytime ready for you at reduced prices in the central warehouse of AMC spare parts, s.r.o., business address: Radíkovice 19, Hradec Králové 503 27, Czech Republic. The spare parts are distributed via postal or courier service directly to your address every working day. Your order has to be received before 4:00 PM in order to be dispatched on the same day.
